ISO14443A Compliant RFID Paper Tickets for Fast and Secure Ticketing
Product description
| product name |
RFID HF Paper Card RFID Ultralight EV1 ISO14443A ticket Printing |
| Material |
paper |
| Working Environment |
Working life: 5-10 years
Store temperature: -25 °C ~80°C
Humidity 20% ~ 90%RH
Working temperature: -40 °C~ 70°C |
| Reading & Writing distance |
1-3cm for HF(depending on field strength and antenna geometry) |
| Application |
Ticket |
| Disclaimer |
The showing picture is only for your reference of our product. All related to intellectual property rights of trademark belongs to trade mark companies. |
Benifits:
- Long read range due to high chip sensitivity
- Ease of tag assembly due to high chip input capacitance
- Consistent performance on different materials
- Reliable operation in multi-reader environment
- Prevention of unauthorized memory access due to
- read protection
- Wide temperature range: -40°C up to +85°C
RFID Ultralight
Features
RFID RF Interface (ISO/IEC 14443 A)
-
Contactless transmission of data and supply energy
-
Operating distance up to 100 mm depending on antenna geometry and reader configuration
-
Operating frequency of 13.56 MHz
-
Data transfer of 106 kbit/s
-
Data integrity of 16-bit CRC, parity, bit coding, bit counting
-
True anticollision
-
7 byte serial number (cascade level 2 according to ISO/IEC 14443-3)
-
Typical ticketing transaction: < 35 ms
-
Fast counter transaction: < 10 ms
EEPROM
-
640-bit or 1312-bit, organized in 20 or 41 pages with 4 bytes per page
-
First 512 bits compatible to MF0ICU1
-
Field programmable read-only locking function per page for the first 512 bits
-
Field programmable read-only locking function per 2 pages above page 15
-
32-bit user definable One-Time Programmable (OTP) area
-
384-bit or 1024-bit freely available user Read/Write area (12 or 32 pages)
-
3 independent, true one-way 24-bit counters on top of the user area
-
Anti-tearing support for counters, OTP area and lock bits
-
Configurable password protection with optional limit of unsuccessful attempts
-
ECC based originality signature
-
Data retention time of 10 years
-
Write endurance 100.000 cycles
-
Write endurance for one-way counters 1.000.000 cycles
FAQ
1. Q. How to order ?
1) Client supply the requirement details & vector artwork.
2) Quotation.
3) Order is confirmed.
4) We send client the PI and artwork proof.
5) PI and artwork proof are confirmed by client, then do the payment.
6) Start production once the payment is confirmed.
7)QC
8) Delivery by DHL /UPS/Fedex/ TNT, or by Sea, or by Air.
2. Q. Can we get free samples?
Yes ,we offer free samples, with shipping and taxes paid by the buyer.
3. Q. What is the minimum order quantity?
The MOQ for dry inlays is 1000pcs, for wet inlays or labels is 1000pcs,for other special tags is 1000pcs. for cards is 1000pcs.
4. Q. What is the lead time?
7-10 days below 20,000pcs after T/T payment, for other products please contact us for details.
5. Q. What is the payment term?
The payment term is T/T, PayPal, Western Union before shipment.
6. Q. What chip inside of your product?
As your request, normally SLE6636/36E original.
you can choose ISSI chip series,SLE chip series,24C chip series and AT88SC chip series etc.
7. Q. After-sale service:
- All products will have been strictly quality checked in house before packing
- All products will be well packed before shipping.
- All our products have 1 year warranty. And we sure the product will be free from maintenance within warranty period.
-
