Seamless Upgrade with Procedures RFID Smart Card RFID Plus X 4K 7bytes Card
Key features
* 2 or 4 Kbytes EEPROM
* Simple fixed memory structure compatible with RFID Classic (RFID Mini, RFID Classic®1k, RFID Classic®4k)
* Memory structure as in RFID Classic®4k (sectors, blocks)
* Unique serial number (4 or 7 byte)
* Multi-sector authentication
* Multi-block read * Anti-tear function for writing AES keys
* Keys can be stored as RFID Classic keys (2 x 48 bit per sector) or AES keys (2 x 128 bit per sector)
* Access conditions freely configurable
* Number of single write operations: 200, 000
RFID Smart Card RFID Plus® (X) 4K 7bytes Card brings increased security to end-user solution providers together with a seamless upgrade of existing infrastructure and services with low cost procedures. This new RFID product is supported by card and reader manufacturers and solution developers, and is the only RFID Classic-compatible mainstream smart card IC featuring pre-issuance of cards prior to infrastructure changes.
| Chip type: |
RFID Plus® (X) 4K 7bytes
|
| Size: |
85.5*54 mm or customer request
|
| Tickness: |
0.86mm
|
| Materials: |
PVC, PET...
|
| Working Frequency: |
13.56MHz
|
| Function: |
Write/Read
|
| Number of single write operations: |
200, 000 |
| Options: |
Magnetic stripe, barcode, embossing etc |
| Surface: |
Glossy/Matt/Frosted |
| Printing: |
custom Silk printing, offset printing |
RFID Plus® (X) 4K
- 2 kB or 4 kB EEPROM
- Simple fixed memory structure compatible with RFID Classic 1K and RFID Classic 4K
- Memory structure identical to RFID Classic 4K (sectors, blocks)
- Access conditions freely configurable
- Supports ISO/IEC 14443-31 UIDs (4-byte UID, 4 Byte NUID, 7-byte UID), optional support of random IDs
- Multi-sector authentication, Multi-block read and write
- AES-128 used for authenticity, confidentiality and integrity
- Anti-tearing mechanism for writing AES keys
- Keys can be stored as RFID CRYPTO1 keys (2 × 48-bit per sector) and as AES keys (2 × 128-bit per sector)
- Full support of virtual card concept
- Proximity check
- Communication speed up to 848 kbit/s
- Number of single write operations: 200000 cycles (typical)
- Common Criteria Certification: EAL4+
smart card personalization support
Offset Printing with CMYK or Pantone colors ,Silk-screen printing with metallicsliver effect Magnetic Stripe HiCo2750, HiCo4000 or LoCo300/ Serial Number or UID number printing/ Signature Panel/ Barcode printing in different types/ Photo personalization/ Chip encoding/ Hologram/ UV printing / Laser Logo / Laser Serial Number /Embossing Number /Thermal Transfer Number
application
public transportation/even ticketing/loyalty system/NFC application(Hotel Key Card,Prepaid Phone Card)/Enterprises, bank, traffic, insurance, super marketing, parking, school, library management, access control ect.(Door Access Control)/Asset Management/ time attendance
Blank card, pre-printed card can do according to your request .Hybrid smart card can be made according to your request .Shipping, packing way can according to your request.Your inquiry is highly appreciated!
company capacity
we always focused on providing to end users and distributors with the better products, faster delivery and more favorable price. We offer products as Inlay, Label, On-Metal Tag, Laundry Tag, Jewelry Tag, paper Ticket, Token, and Wristband etc. Also we can offer custom printed, roll, fanfold, sheet, digital and stock labels, inlay or tags. Our commitment is to meet your most demanding Tag needs.
